All Lift Cranes L186 | Light Duty Floor Mounted Jib Crane 1/2 Ton Capacity

All Lift Cranes Half Ton Light Duty Floor Mounted Jib Crane (L-Series)

Features:

• Half Ton: Perfect for light lifting tasks.
• 360° Revolve: Rolled steel I-beam with tapered flange for smooth and presenting trolley travel.
• Base Plate Reinforcement: Provide one with min displacement.
• Limit (Removable) Safety End Stops: Limit trolley travel for safe operation.
• Customizable Options: Tagline kitsOutdoor/Stainless steel collector rings

Product Description

All Lift Cranes L-Series Half Ton Light Duty Floor Mounted Jib Crane is an excellent choice for light industrial lifting applications. The crane is intended for uses including but not limited to welding stations, small assembly lines, and light labor.

Designed for Light-Duty Capability

This jib crane has a capacity of half ton and is best suited for handling lighter loads with total precision and control. Heavy-wall structural steel pipe mast with reinforced base plate keep the unit with minimal deflection and perfectly aligned during frequent operation.

Smooth and Safe Operation

Rolled steel I-beam rotates 360°, tapered flange provides smooth trolley travel, removable safety end stops limit trolley movement. This design provides operators the ability to control the load with ease, even in tight spaces.

Versatile Applications

• Welding Stations: Align materials quickly and accurately.
• Micro Assembly Lines: Optimize production processes.
• Light Manual Work: Efficiently move and transport tools, parts and equipment.

Customizable Options

• Customize the crane to fit your precise requirements with additional options for:
• The S-Hook makes it possible to handle (position) loads with ease.
• Outdoor & Stainless Steel Configurations: Improve robustness for tough environments.
• These rings allow powered hoists to spin 360° without getting caught.

Easy to Install

For the L-Series jib crane, you should have a 3′ deep cement foundation with used rebar (5/8″ diameter, 12″ on center). Based on span, foundations are 4’ square or 5’ square. And in the end, for long-term using, it can promise you a more stable and secure installation.

Introducing the All Lift Cranes L-Series Half Ton Light Duty Floor Mounted Jib Crane: an efficient and beneficial addition to your workplace!
